Rego 3/4" Esv With Nitrile Seat 54gpm - Lp - A006006

Rego 3/4" Esv With Nitrile Seat 54gpm - Lp - A006006

Regular price $ 1,073.10 USD
Regular price Sale price $ 1,073.10 USD
Sale Call To Pre-Order

Ships within 5-7 business days

Features:

  • Meets NFPA 58 and UL Requirements
  • Fusible Element is located in the Thermal Fuse assembly, which acts at the Latch Open and Close Trigger - When exposed to fire, the Element melts at 212° F, (100° C,) allowing the shaft to return to the Closed Position
  • Valve can be closed by Remote Cable or Pneumatic Actuator
  • Valve can be closed by simply pushing the Operating Lever down - it is not necessary to trip the Close Trigger
  • Sturdy Rugged Construction
  • Will withstand Hydraulic Shock of Sudden Closings, Piping Strains, and Temperature Variations
  • Valve has only two moving parts - Stem and Close/Thermal Trigger
  • UL listed for use in LP-Gas and NH3 as an Emergency and Operating Shut-Off Valve
  • Stem Seals are Spring Loaded for Leak Free Performance at Low Temperatures/Pressures
  • Seat Disc is retained by a Metal Seat to minimize leakage in case of Direct Fire Impingement
  • Quick Closing regardless if the Pump is running or not

Materials:

  • Body..........................................................Ductile Iron Cad Plated
  • Stem............................................................................Stainless Steel
  • Seat Disc................................................................................... Nitrile
  • Springs...................................................................... Stainless Steel
  • Packing.......................................................................................Teflon
